PLQ-30 Passbook Printer
| Brand | - | EPSON |
| Model | - | PLQ-30 |
| Printer Type | PRINTING METHOD | 24 pins Impact Dot Matrix |
| Colour | Black | |
| PRINT DIRECTION | Bi-direction with logic seeking | |
| Control Code | PR2, WNI4915, IBM4722, ESC / P2, ESC / P2 + ESC / MC, IBM PPDS emulation | |
| Printer Speed | PR2 Emulation | Ultra High Speed Draft :- 585 cps (10 cpi) High Speed Draft :- 520 cps (10 cpi) / 468 cps (12 cpi) Draft :- 390 cps (10 cpi) / 390 cps (12 cpi) NLQ :- 195 cps (10 cpi) / 195 cps (12 cpi) LQ :- 130 cps (10 cpi) / 156 cps (12 cpi) |
| ESC / P2, Others | Ultra High Speed Draft :- 585 cps (10 cpi) High Speed Draft :- 520 cps (10 cpi) / 624 cps (12 cpi) Draft :- 390 cps (10 cpi) / 468 cps (12 cpi) LQ :- 130 cps (10 cpi) / 156 cps (12 cpi) |
|
| IBM4722 | Draft :- 390 cps (10 cpi) NLQ :- 260 cps (10 cpi) LQ :- 130 cps (10 cpi) |
|
| Print Characteristics | Character Table | International, PC-437 International |
| Barcode | EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Coda bar (NW-7), Industrial 2 of 5 | |
| Printable Columns | Pitch | 10 cpi: 94 cpl, 12 cpi: 112 cpl |
| Paper / Media Handling | Paper Path | 3Manual Insertion (front in, front out / front in, rear out) |
| Passbook | Width :- 110 - 241.3 mm Length :- Horizontal: 127 - 220 mm, Vertical: 85 - 220 mm Thickness :- Maximum: 2.6 mm, Cover Page: 0.2 - 0.5 mm, Each Page: 0.1 - 0.15 mm |
|
| Cut Sheet Size | Width:- 65 - 245 mm Length:- 67 - 297 mm Thickness:-Single Sheet: 0.065 - 0.19 mm | Multi Part: 0.12 - 0.53 mm |
|
| Acoustic Noise | PLQ-30: Approx. 52 db(A) PLQ-30M: Approx. 55 dB(A) |
|
| Copy | 1 original + 6 copies | |
| Line Spacing | 4.23 mm | |
| Interface | - | Bi-directional parallel interface (IEEE-1284 nibble mode supported), Serial I/F, High Speed USB 2.0 |
| Ribbon Cartridge | Colour | Black |
| Type | Fabric | |
| Ribbon Life | Approx. 5 million characters (LQ 10 cpi, 48 dots / character). Approx. 10 million characters (Draft 10 cpi, 24 dots / character) | |
| Reliability | Mean Print Volume Between Failure | 7 million lines |
| Mean Print Volume Before Failure | 12,000 POH | |
| Print Head Life | 400 million strokes / wire | |
| Environmental Conditions | Temperature | Operating: 5 - 35 °C |
| Humidity | Operating: 10 - 80 % RH | |
| Electrical Specification | Rated Voltage | AC 220 - 240 V |
| Rated Frequency | 50 - 60 Hz | |
| Power Consumption | In operation: Approx. 64 W Sleep mode: Approx. 4.5 W |
|
| Dimensions & Weight | Dimensions (W x D x H) | 384 x 280 x 203 (mm) |
| Weight | Approx. 8.0 kg (17.6 lb) |
