| Panel specification |
| Brand |
HP |
| Color |
Black |
| Type |
17-inch Active Matrix TFT (thin film transistor) |
| Viewable Area (diagonal) |
43.2 cm (17 inch) |
| Screen Opening (W x H) |
339 x 271 mm |
| Native Resolution |
1280 x 1024 @ 60 Hz (recommended) (SXGA) |
| Panel Type |
TN |
| Viewing Angle |
160 degrees horizontal/160 degrees vertical (10:1 minimum contrast ratio) |
| Brightness (typical) |
250 nits (cd/m2) |
| Contrast Ratio (typical) |
1000:1 |
| Aspect Ratio |
5:4 |
| Response Rate (typical)1
|
5 ms (rise + fall) |
| Pixel Pitch |
0.294 mm |
| Backlight Lamp Life (to half brightness) |
50K hours |
| Color Gamut |
72% |
| Interface/Performance |
| Horizontal Frequency |
24 to 83 kHz |
| Vertical Frequency |
50 to 76 Hz |
| Native Resolution |
1280 x 1024 @ 60 Hz (recommended) (SXGA) |
| Maximum Resolution (Digital) |
N/A |
| Max Pixel Clock Speed |
140 MHz |
| User Programmable Modes |
Yes, 8 |
| Anti-Glare |
Yes |
| Anti-Static |
Yes |
| Default Color Temperature |
6500 degrees Kelvin |
| Video input specification |
| Plug and Play |
Yes |
| Input Signal |
15 pin D-sub (Analog VGA) |
| Input Impedance |
75 ohms (2 % value change allowed) |
| Sync Input |
TTL separate synch |
| Video Cable |
Detachable 15-pin D-sub mini connector |
| Video Cable Length |
1.8 m (70.8 in) |
| Power Features |
| Input Voltage |
100 - 240 V ac |
| Nominal Current |
< 0.50 Ampere |
| Frequency |
50/60 Hz |
| Maximum |
< 28 W |
| Typical |
24 W |
| Power Saving |
< 2 W |
| Power Cable Length |
1.9 m (74.8 in); detachable |
| Environmental |
| Operating Temperature |
5° to 35° C (41° to 95° F) non-condensing |
| Non operating Temperature |
-20° to 60° C (-4° to 140° F) |
| Operating Humidity |
20% to 80%, non-condensing |
| Non operating Humidity |
5% to 90% |
| Operating Altitude |
0 to 5,000 m (0 to 16,404 ft) |
| Non operating Altitude |
0 to 12,192 m (0 to 40,000 ft) |
| Dimensions & Weight |
| Dimensions with stand( H x W x D ) |
386 x 377 x 206 mm |
| Dimensions without stand( H x W x D ) |
317 x 377 x 58 mm |
| Weight (panel only - for VESA mount) |
4.6 kg |
| Weight (with packaging) |
5.8 kg |
